| Appearance: | Dark Red Granule | Package: | 25kg Bag |
|---|---|---|---|
| Process Method: | Injection Process | Features1: | Improved Heat Resistance |
| Features2: | Good Flow | Features3: | Improved Impact Strength |
| High Light: | thermosetting plastic resin,cresol novolac resin |
||
Phenolic moulding compound(PMC) are produced with with heated rollers or extruders.
Treatment of a mixture of phenolic novolac resin,hexamethylenetetramine, fillers and
additives leads to an intermediate, the actual moulding material. The polycondensation is
driven so far that the moulding material in the final molding step can still flow, but so that
the final cross-linking occurs very quickly. Especially important processing properties are
good flow characteristics and rapid curing.
Used under the upper temperature limit of 250℃ and the upper voltage limit of 220V
Suitable for handles and knob of electric oven and top grade pan, coil holders
☆ Good Fluidity
☆ Rapid Curing
☆ Excellent Heat Resistance
Specification:
| Physical properties | Typical value | Unit | Standard |
| Density | 1.5 | g/cm3 | ISO1183 |
| Apparent Density | 0.5 | g/cm3 | ISO60 |
| Moulding Shrinkage | 0.9 | % | ISO2557 |
| Water absorbency(24h / 23°C) | 20 | mg | ISO62 |
| Thermal properties | |||
| Temperature of deflection under load | 140 | ℃ | ISO75-2 |
| Temperature resistance | 180 | ℃ | DIN44904 |
| Mechanical properties | |||
| Flexural strength | 80 | Mpa | ISO178 |
| Charpy Impact strength | 1.55 | KJ/m2 | ISO179-1 |
| Charpy notched Impact strength | 6.5 | KJ/m2 | ISO179-1 |
| Electrical properties | |||
| Electrical strength | 10 | KV/mm | IEC60243-1 |
| Insulation resistance | 1010 | ohm | IEC60167 |
| Surface resistivity | 1012 | ohm | IEC60093 |
| Volume resistivity | 1012 | ohm*cm | IEC60093 |
| Dissipation factor(1MHz) tanδ | 0.1 | - | IEC60250 |
| Proof Tracking Index | 150 | - | IEC60112 |
Packing&Storage
the package is in 25KGS paper-plastics bag
The storage life of this product is 12 months in a cool and dry place in original closed bags
FAQ
Q1:Are you a trader or manufactuer?
Established in 1993, located in Wangdian town,Jiaxing City, 100kms far from Shanghai, JIAMIN are one of excellent manufacturers of moulding compounds in China, with annual capacity of 30,000 tons.
We produce different quality moulding compounds for various uses, from household handles to electric appliances, from meters parts to automotive parts. Backed by decades of experience, we are able to help you shape a better product at saving cost.
We have been working under ISO 9001 management system, ISO14001 environment management systems since 2008.
JIAXING HONING IMPORT&EXPORT CO.,LTD is our exclusive sales agent for the oversea market. Our moulding compounds have been sold all over China domestic market and oversea market. Most of our moulding compounds are certified by UL94 ,tested by SGS according to RoHS.
Our advantage:
R&D team offer Complete technical support
a long-term and reliable supplier
Superior-quality materials offered at competitive prices
