Product Details:
Payment & Shipping Terms:
|
| Appearance: | Orange Granule | Package: | 25kg Bag |
|---|---|---|---|
| Process Method: | Compression And Injection | Features1: | Improved Heat Resistance |
| Features2: | Fast Cure | Features3: | Improved Impact Strength |
| High Light: | thermosetting plastic resin,cresol novolac resin |
||
Phenolic moulding compound(PMC) are produced with with heated rollers or extruders.
Treatment of a mixture of phenolic novolac resin,hexamethylenetetramine, fillers and
additives leads to an intermediate, the actual moulding material. The polycondensation is
driven so far that the moulding material in the final molding step can still flow, but so that
the final cross-linking occurs very quickly. Especially important processing properties are
good flow characteristics and rapid curing.
Used under the upper temperature limit of 250℃ and the upper voltage limit of 220V
Suitable for handles and knob of electric oven and top grade pan, coil holders
☆ Improved Impact Strength
☆ Rapid Curing
☆ Excellent Heat Resistance
Specification:
| Physical properties | Typical value | Unit | Standard |
| Density | 1.5 | g/cm3 | ISO1183 |
| Apparent Density | 0.5 | g/cm3 | ISO60 |
| Moulding Shrinkage | 0.9 | % | ISO2557 |
| Water absorbency(24h / 23°C) | 20 | mg | ISO62 |
| Thermal properties | |||
| Temperature of deflection under load | 140 | ℃ | ISO75-2 |
| Temperature resistance | 180 | ℃ | DIN44904 |
| Mechanical properties | |||
| Flexural strength | 80 | Mpa | ISO178 |
| Charpy Impact strength | 1.55 | KJ/m2 | ISO179-1 |
| Charpy notched Impact strength | 6.5 | KJ/m2 | ISO179-1 |
| Electrical properties | |||
| Electrical strength | 10 | KV/mm | IEC60243-1 |
| Insulation resistance | 1010 | ohm | IEC60167 |
| Surface resistivity | 1012 | ohm | IEC60093 |
| Volume resistivity | 1012 | ohm*cm | IEC60093 |
| Dissipation factor(1MHz) tanδ | 0.1 | - | IEC60250 |
| Proof Tracking Index | 150 | - | IEC60112 |
Packing&Storage
the package is in 25KGS paper-plastics bag
The storage life of this product is 12 months in a cool and dry place in original closed bags
FAQ
Q1: Are you a trader or manufactuer?
Established in 1993, located in Wangdian town,Jiaxing City, 100kms far from Shanghai, JIAMIN are one of excellent manufacturers of moulding compounds in China, with annual capacity of 30,000 tons.
We produce different quality moulding compounds for various uses, from household handles to electric appliances, from meters parts to automotive parts. Backed by decades of experience, we are able to help you shape a better product at saving cost.
Our advantage:
R&D team offer Complete technical support
a long-term and reliable supplier
Superior-quality materials offered at competitive prices
Q2: Could you make the bag marking as I request?
The bag marking is customized. You can decide the brand name, product name, contact information and so
on.
Q3: Could you make a new color in a very short time?
Yes, after we get your color sample, we normally can make a new color in one week. If you are really worried
about time, we can try our best to make it faster.
